Jib Crane Types
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast that measures up to 20 feet long. Jib cranes can move loads between any areas within the boom's arc of rotation. Light duty models are utilized in warehouses and factories for loads weighing as much as 5 tons. The website BestJibCranes.com features the major jib crane models as being either wall-mounted, mast mounted or free-standing.
Free Standing
Free-standing jib cranes could stand alone not requiring support from the building structure. The horizontal boom in this particular situation is connected to a pivoting vertical column which is anchored firmly to the floor of the building. This kind of jib crane needs a foundation made of either concrete or steel and is able to rotate a full 360 degrees.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the bottom and the top. These pivots are attached to the building floor and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the benefit of not requiring the massive foundation required for free-standing units.
Wall Mounted
The wall-mounted jib cranes provide a horizontal boom that is connected to the building wall rather than the regular vertical column. These machine offer up to 200 degrees of rotation and are ideal in areas where the full 360 degree rotation is not required.
Depending on how the boom is supported, there are two model varieties. One kind utilizes a tie rod from above the boom which is attached to the wall. The other type supports the boom from below by utilizing a cantilever brace that is also attached to the wall.
